AISI 304 ERW Stainless Steel Pipe 20 Inch , Annealed Stainless Steel Tubing

    Buy cheap AISI 304 ERW Stainless Steel Pipe 20 Inch , Annealed Stainless Steel Tubing from wholesalers

    Buy cheap AISI 304 ERW Stainless Steel Pipe 20 Inch , Annealed Stainless Steel Tubing from wholesalers
    • Buy cheap AISI 304 ERW Stainless Steel Pipe 20 Inch , Annealed Stainless Steel Tubing from wholesalers
    • Buy cheap AISI 304 ERW Stainless Steel Pipe 20 Inch , Annealed Stainless Steel Tubing from wholesalers

    AISI 304 ERW Stainless Steel Pipe 20 Inch , Annealed Stainless Steel Tubing

    Ask Lasest Price
    Brand Name : Hainer Steel
    Model Number : 304/304L,316L,310S, 904L etc.
    Certification : ISO9001,SGS,CQC,BV, TUV etc.
    Price : Negotiation
    Payment Terms : T/T, L/C at sight
    Supply Ability : 5000Tons/Month
    Delivery Time : 10-15 days
    • Product Details
    • Company Profile

    AISI 304 ERW Stainless Steel Pipe 20 Inch , Annealed Stainless Steel Tubing


    AISI 304 ERW Stainless Steel Pipe 20 Inch , Annealed Stainless Steel Tubing


    QuickDetail:



    ProductName



    ERWWeldedStainlessSteelPipe



    SurfaceFinish



    1.2BFinish2.PickledFinished3.Annealed&Pickled



    Material



    304/L,316L/Ti,310Setc.



    OutsideDiameter



    20mm-2000mm



    WallThickness



    1mm,1.2mm,1.5mm,2.0mm...30mm.



    Length



    1000mm,2000mm,3000mm....12000mm



    Market



    USA,Canada,Japanese,Europeanetc.



    Description:


    1. Product Item No.: 0010welded-Cosco Steel


    2. Type: Round Or Oval


    3. Material: Main


    1. 4301/ SUS304/ AISI304/ S30400,


    1. 4306/ SUS304L/ AISI304L/ S30403,


    1. 4404/ SUS316L/ AISI316L/ S31603, etc.


    4.Standard:


    GB/T12771-2008, ASTM A312, ASTM A789, JIS G3448,


    DIN EN10216-5, DIN EN10217-7, etc.


    5. Size: 1/2” to 48”


    6. Wall Thickness: Sch5s,Sch10s,Sch40S


    7. Marking: Registered logo,Heat Number,Steel Grade,Standard,Size


    8. H.S Code: 7306.4000



    Applications:


    This type welded tubes/pipes be used in
    Industrial fluid conveying pipes
    Mechanical structural tubes
    Heat ex-changer and condenser tubes
    Walled water tubes
    Larger caliber industrial welded pipes etc.


    Specifications


    Designation:A312/A312M-04a


    StandardspecificationsForSeamless,Welded,AndHeavilyColdWorkedAustenitic


    StainlessSteelPipe



    ManufactureProcess



    ERWWelded(ELD)Pipe






    QualityInspection







    1. MetallographicAnalysis
    2. PhysicalAndChemicalAnalysis
    3. SpecificationEccentricityTest
    4. MechanicalTest
    5. PMITest
    6. EddyCurrentTest
    7. Large-SizeUltrasonicFlawTest
    8. UltrasonicFlatTest
    9. ThicknessTestetc.





    MechanicalRequirements



    GradeUNSDesignationTensileStrengthYieldStrength


    MinKsi[Mpa] MinKsi[Mpa]


    TP304S30400 75[515] 30[205]


    TP304LS30403 70[485] 25[170]


    TP309SS30908 75[515] 30[205]


    TP310SS31008 75[515] 30[205]


    TP316LS31603 70[485] 25[170]


    ..................




    1. SpecificationNo.
    2. Pipe
    3. Grade
    4. NPS
    5. Wall
    6. SMLESORWELDED...



    • ASTMA312

    • P

    • TP304

    • 12IN

    • 0.375IN

    • WELDED.....
