    Annealed Sch 40 / 80 Stainless Steel Heat Exchanger Tubes S32101 S32205 S31803

    Ask Lasest Price
    Brand Name : Cosco Steel
    Model Number : S32101 S32205 S31803 etc.
    Certification : ISO,SGS,CQC,etc.
    Price : Negotiation
    Payment Terms : T/T, L/C at sight
    Supply Ability : 600Tons/Month
    Delivery Time : 10-15 days
    • Product Details
    • Company Profile

    Annealed Sch 40 / 80 Stainless Steel Heat Exchanger Tubes S32101 S32205 S31803


    Annealed Sch 40 / 80 Stainless Steel Heat Exchanger Tubes S32101 S32205 S31803

    QuickDetail:
    Standard:JIS,AISI,ASTM,GB,DIN,EN
    Steel Grade:304, 304L, 304LN, 316, 316L, 316LN, 317, 317L, 321, 347, 439, etc.
    Type:Seamless, Welded
    Thickness:0.1-3.8mm
    Outer Diameter:6-219mm
    Surface:Satin / Hairline
    Heat treatment: Available
    Length tolerance:±0.05mm
    WT tolerance:±0.02mm
    Description:

    1. Heat-exchangerseamlesstubes
    2. Materials:

    1.4301/SUS304/AISI304/S30400,
    1.4306/SUS304L/AISI304L/S30403,
    1.4404/SUS316L/AISI316L/S31603,etc.

    1. Type:Round
    2. Marking:Registeredlogo,HeatNumber,SteelGrade,Standard,Size
    3. Packing:woodenbox
    4. H.SCode:7304.4190
    5. OrderingInformation:Itshallbetheresponsibilityofthepurchasertospecifyall

    Requirementsthatarenecessaryforproductsunderthisspecification.Suchrequirementstobeconsidered
    included,butarenotlimitedto,thefollowing:
    7.1.1Quantity(feet,meters,ornumberoflengths)
    7.1.2Nameofmaterial(seamlesstubes)
    7.1.3Grade(stainlesssteel)
    7.1.4Size(outsiderdiameter,minimumwallthickness)
    7.1.5Length(specificorrandom)
    7.1.6Hydro-staticTestorNondestructiveElectricTest
    7.1.7Condition(hotfinishedorcoldfinished)
    7.1.8Specificationdesignationandyearofissue
    7.1.9Specialrequirementsandanysupplementaryrequirementsselected

    merican Standard

    Austenitic Steel:
    TP304,TP304L,TP304H,TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H,
    TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…
    Duplex Steel :
    S32101,S32205,S31803,S32304,S32750, S32760
    Others:TP405,TP409, TP410, TP430, TP439,...

    European Standard

    1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438,
    1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501

    Russia Standard

    08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,
    10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,
    12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т,


    Applications:
    We,thistypeseamlessandweldedfoodsteeltubebewidelyusedinkindsofindustries:

    1. Petrochemicalindustry,Electricity,
    2. Nuclearenergy,
    3. Chemicalfertilizer,Boiler,Lighttextile,
    4. Spinningandweavingindustry,
    5. Powerindustry,
    6. Pharmacyandbiologyetc.


    Specification:
    Designation:A213/A213M-04
    StandardspecificationsForSeamlessFerriticandAusteniticAlloy-SteelBoilerr,
    Superheater,andHeat-exchangerTubes
    TensileandHardnessRequirements


    Grade


    UNS

    Tensile
    Strength

    Yield
    Strength

    Elongationin
    2in.
    Or50mm


    Hardness,Max

    Designation

    Min,Ksi
    [Mpa]

    Min,Ksi
    [Mpa]

    Min,%

    Brinell/Vickers

    Rockwell


    Stainlesssteels

    TP201

    S20100

    95[655]

    38[260]

    35

    219HBW/230HV

    95HRB

    TP202

    S20200

    90[620]

    45[310]

    35

    219HBW/230HV

    95HRB

    TP304

    S30400

    75[515]

    30[205]

    35

    192HVW/200HV

    90HRB

    TP304L

    S30403

    70[485]

    25[170]

    35

    192HVW/200HV

    90HRB

    TP309S

    S30908

    75[515]

    30[205]

    35

    192HVW/200HV

    90HRB

    TP310S

    S31008

    75[515]

    30[205]

    35

    192HVW/200HV

    90HRB

    TP316L

    S31603

    70[485]

    25[170]

    35

    192HVW/200HV

    90HRB

    TP321

    S32100

    75[515]

    30[205]

    35

    192HVW/200HV

    90HRB

    TP347

    S34700

    75[515]

    30[205]

    35

    192HVW/200HV

    90HRB


    Ouradvantage

    1. 100%TubeHydro-staticTestorNondestructiveElectricTest
    2. 100%EddyCurrentTest
    3. 100%UltrasonicDetectorTestifcustomerrequested
    4. TensileandHardnessTestforeachHeatNo.’smaterial
    5. 100%Annealing&SolutionandPickling
